RH basic white
Newly designed, economic magnetic stirrer with heating. Bushing according to DIN 12878 for connecting an electronic contact thermometer, such as the ETS-D5. Highly accurate temperature control is possible with sensor placed directly in the medium. High heat output of 600 watts and white ceramic heating plate ensures rapid heating. Adjustable safety temperature from 100 to 360 °C.
Soft-start of the stirring motor
Includes M 10 thread for a support rod
Strong magnetic field and wide speed range for volumes up to 15 liters
| 攪拌點位數目 | 1 |
| 最大攪拌量 (H2O) | 15 l |
| 電機輸出功率 | 2 W |
| 旋轉方向 | 左 |
| 速度顯示設定值 | 刻度 |
| 轉速控制 | 控制旋鈕 |
| 速度范圍 | 100 - 2000 rpm |
| 攪拌子長度 | 20 - 80 mm |
| 加熱盤自熱（室溫:22°C/保持:1小時） | 28 +K |
| 加熱輸出功率 | 600 W |
| 溫度顯示設定值 | 刻度 |
| 溫度單位 | ℃ |
| 加熱溫度范圍 | 50 - 320 °C |
| 加熱溫度控制 | 刻度 |
| Temperature setting range | 0 - 320 °C |
| 外接溫度傳感器接口 | ETS-D5 |
| 介質溫度傳感器的特性 | 1L M50硅油，裝在H1500中 |
| 介質加熱速率 | 6 K/min |
| 可調安全溫度回路最小值 | 100 - 360 °C |
| 工作盤材質 | 技術搪瓷 |
| 工作盤外形尺寸 | ? 135 mm |
| 外形尺寸 | 160 x 100 x 250 mm |
| 重量 | 3.135 kg |
| 允許環境溫度 | 5 - 40 °C |
| 允許相對濕度 | 80 % |
| DIN EN 60529 保護方式 | IP 21 |
| 電壓 | 230 / 115 / 100 V |
| 頻率 | 50/60 Hz |
| 儀器輸入功率 | 620 W |
